AR Blue Clean AR630 Pressure Washer V2

$945.00 USD
$945.00 USD
Buy Now, Reserve Your Spot
    Shipping Information

    This item is shipped from our warehouse at OGHQ in Lady Lake, FL. Shipping costs are calculated at checkout.

    AR-AR630-WOGW-OG

    3/8" NPT Outlet

    The M22 fitting has been replaced with the industry standard 3/8" NPT thread. We will include an adapter to convert this to M22 threads. So if you already have an M22 14mm fitting, it can be attached. If not, you'll want to pick one up.

    Sleeker Design

    Thanks to the redesigned motor and pump connection, the AR630 now has a reduced footprint and a sleeker appearance. Did we mention the case is all black now, too?

    Adjustable TSS

    The TSS system has been redesigned to allow for more versatility. Through your power switch, you can choose between a traditional total stop system (the machine turns off when the trigger is released) and a constantly running unit.

    Durability improvements

    Utilizing AR's industrial-grade RC series of pumps, the new AR630 sees improvements in durability, efficiency, and stronger internal design. The TSS system also has improved functionality, reliability, and a new harness to support it all.

    Easy to Maintain

    Thanks to the new pump head, maintenance has never been easier to keep your machine running. A fully rebuildable pump will keep this machine running for years to come.

    THIS IS EXTREMELY IMPORTANT: THIS UNIT REQUIRES A DEDICATED 20-AMP CIRCUIT. IT WILL NOT WORK ON A 15-AMP!

    When I tested the original AR630-TSS, I was surprised at how well it performed. It outperformed the Kranzle K1322TS, K1122TST, and Comet Static 1700, with 980 PSI at 2.35 GPM (with our accessories), while still being in a mid-tier price point. While I still prefer the Kranzles, this pressure washer is no slouch.

    AR has now updated the pressure washer to make it better. You'll notice there is no "TSS" at the end of the model number. That is because they only make one version of this pressure washer now. The new power switch on this unit lets us toggle on and off the TSS (Total Stop System). For some industrial use cases, you may want to have the pressure washer constantly run, but for us pro-sumers, we want to keep the TSS turned on, allowing the pressure washer to turn off when you release the trigger.

    Of course, I still need to test this new one to make sure it is up to par. Just like the last unit, it comes with a 20-amp plug, so you will need to make sure your outlet can accept that. I tested it at 980 PSI and 2.35 GPM, slightly up from the previous version. While the price has gone up compared to the previous version, it is still a value for what you are getting — serviceability, reliability, and great performance. We still recommend using a 1.25mm orifice in your foam cannon and a 5.0 nozzle size.

    As you can see from the photos, this pressure washer has also undergone some aesthetic changes. The motor/pump integration has been changed so that the overall machine is smaller and sleeker. AR also updated the pump head and TSS to be more durable and reliable.

    Just like the last version, there is also a hot water version. We have found that it is not necessary to purchase that version because this unit can handle up to 120°F, which is plenty warm for washing cars in cold weather. The hot water option can handle up to 180°F, so if you need something that can handle that temperature of water, reach out to our support team, and we can order one for you.

    x1 - AR Blue Clean AR630 Pressure Washer V2
    x1 - Vented Oil Cap
    x1 - 3/8" Female to M22 14mm Adapter

    Obsessed Garage Testing

    • Tested Flow: 2.35 GPM
    • Tested PSI: 980
    • Suggested Nozzle Size: 5.0
    • Foam Cannon Orifice Size: 1.25
    • Loudness w/ OG Sprayer: 68 DB

    Manufacture Specifications

    • Max PSI: 1600
    • Rated PSI: 1400
    • Max GPM: 2.3
    • Rated GPM: 2.1
    • Motor: Single-phase Induction
    • Power Requirements: 120V / 20AMP / 60Hz
    • Weight: 67 lbs
    • Pump: Triplex ceramic piston with rod-crank design
    • Temperature Tolerance: Up to 122°F (50°C)
    • Modes: TSS (Total Stop), Bypass (Continuous Run), Off
