  • For ETA See Reserve Your Spot Info Below
Tier
Inlet Hose Length
Shipping
Regular price $1,553.16
/

I’ll have to try and contain myself talking about The Kranzle K1322TS Portable Solution. If you’re looking for a less noisy, high flow, fit/finish, top-quality pressure washer with the proper accessories (sprayer, wand, hose) this is undoubtedly the solution you want.

Kranzle’s K1322TS is a German-built pressure washer that has all the right components and will be your pressure washer for many years to come. This unit is very close to the K1122TST. It has the same body and weight as the K1622TS. The one difference between the two pressure washers is the way that it (the K1322TS) outputs water. It has a PSI of 1300 and does 2.1 GPM. It matches the performance of the K1122TST which is what I would call Kranzle’s cornerstone pressure washer.

What matters to me is flow and not pressure. Water flow is measured in GPM (gallons per minute). The higher the GPM, the more surface area a pressure washer can clean in a minute. I wanted to mention that so you know that this is both the best and right unit for optimal car cleaning.

The K1322TS in comparison to the K1622TS will require a dedicated 20 amp circuit whereas the K1622 only requires a 15 amp circuit. The reason being is you’ll have more flow. Adding in the foam cannon, you’ll be drawing more power. So, be sure you have the proper wattage before you build out your plan.

What makes this portable solution a great choice is being able to move about vs having a fixed setup. If you’re someone who doesn’t want to have a wall mount solution or if you’re a mobile detailer, this will definitely be a sensible purchase.

When I first started on this quest for the perfect pressure washer what I really wanted for all of us was a small, compact pump that I could put on a shelf that looks and works like the Kranzle K1122TST. That is the main component of my Kranzle K1122TST Portable Pressure Washing Solution

Empowering you to make a choice between mounting your pressure or having a portable solution like this one was always part of my vision.

What I really like about this revamp we’ve done with our pressure washing kits is that we’re giving you more options. You’ll have three tiers available to choose from. Basic, advanced, and ultimate. Each package comes with upgraded fittings (Brass or Stainless Steel), an upgraded sprayer/wand, a 50’ High-Pressure, and either an original foam cannon or MTM’s latest PF22.2 foam cannon

You’ll see some similarities in these packages but the most obvious difference will be the sprayer and wand combo you’re getting. I want to discuss all three of these products in greater detail to give you a sense of awesomeness you’ll be purchasing.

The SGS-28 in our basic package is a well-built, swiveling sprayer that was based on the SG-28, but has all stainless steel internals. The reason why you want a swiveling sprayer is because it alleviates the issue of the pressure washer hose getting tangled and twisted.

The Original Mosmatic Sprayer in our advanced package has a swivel as well. The difference is that the swivel on the advanced sprayer is made by Mosmatic and is of much higher quality - it swivels much smoother. The trigger mechanism is also a lot more stout, yet requires very little effort to engage. I still install MTM fittings on the Original Mosmatic Sprayer to help keep costs down.

Finally, the OG Spec Mosmatic Swiveling Sprayer. This is my pride and joy. Lots of money and time went into developing this sprayer. This piece uses all the best connections and hardware available in the market. It also swivels but the swivel and QD (quick disconnect) is built into the handle, reducing the bulk on the inlet of the sprayer, making it much more ergonomic.

This kit isn’t complete without the wand. I have two options: the Original Mosmatic Stainless Steel Wand that comes in the basic and advanced kits and the OG Spec Mosmatic Stainless Steel Wand that comes in the ultimate kit. These wands both have a 20° bend in them to make rinsing the roof or the lower portions of your car easier. The notable differences between these two are the fittings and the rubber nozzle protector. The Original Mosmatic Wand uses MTM fittings and has a nozzle protector installed on the wand already. The OG Spec Wand uses Mosmatic fittings and has no nozzle protector. This is because the nozzles that come in the Ultimate Kit have the protector.

Nozzles are also an important part of your pressure washer accessories and need to be upgraded. The nozzles that come with the pressure washer are prioritizing pressure over flow. For washing cars, flow is king. The nozzles I provide are some of the best out there. In the basic and advanced kits, you get a 4-pack of stainless steel nozzles from MTM. In the ultimate kit, you get the OG Spec Mosmatic Nozzle Assembly.

And last but not least, our pressure washer hoses. Regardless of what package you decide to go with (basic, advanced, or ultimate), each one comes with only a 50’ High-Pressure hose. The quality of these hoses are definitely legit. You’ve heard me talk about how I bought 6 different hoses when I built the wash bay at my old house. I did and I’m not going to apologize for it.

Our  High-Pressure hose is a single wire hose that is much more pliable than the 2-wire hoses you’ll see out there. Plus, for car washing, we don’t need a 2-wire. It also has a smooth jacket that is good for when you want to avoid messing up your floor with marks. It’s the right hose for the right pressure washer. It’s just right.

If you were sitting across from me and asked the question, “Matt, what’s the best option for a portable solution?” My response would be, “This one.”

FAQ & Support

Ships from Kranzle USA in Maryland. Free shipping to anywhere in the Continental US. If you are in Canada, please select the “Canada” shipping option.

If you are looking to ship to Hawaii, Alaska, or Puerto Rico, please Submit a Request for a shipping quote for the Kranzle machine that is drop shipped. Please include your address in the request.

If you purchase anything else from us along with this pressure washer, you will get a shipping update from us that makes it look like everything has shipped together.

If you purchase a quicker shipping service at checkout, this will not change the speed of when the pressure washer ships and is delivered. Selecting a quicker shipping option at checkout only applies to the items shipped from OGHQ.

The pressure washer tracking information will be sent separately from the rest of the shipment.

User Manual
Kranzle K1322TS Operating manual with spare parts list

Support Articles
What is the best pressure washer?
Will a Kranzle pressure washer work with a water tank?
Can I use a Kranzle with a generator? What wattage do I need?
How To Buy: Setting up a Kranzle K1322TS for a Mobile Detailer Tralier/Van - Generator and Water Tank.
What is the difference between the K1622TS and the K1322TS? (Hint: Just get the K1322TS)
Why Should I Upgrade My Sprayer and Which One Should I Get? - Upgrading Your Sprayer

Pressure Washer Fittings 101: Fittings and QD Naming
Pressure Washer Fittings 102: Applications and Usage
Pressure Washer Fittings 103: Spray Nozzles

Why is my gun or wand (1/4" Coupler) leaking from the outlet?
Why is my 3/8" coupler leaking from the end?
Why didn't I receive all of my garden hose quick disconnects? I only received two garden hose fittings!
Troubleshooting: Garden hose / inlet hose is leaking at the threads.

How To: Properly Shorten Kranzle Power Cord
How To: Kranzle Oil Change
How To: Set up your inlet hose or garden hose with quick disconnects
How To: Kranzle Teardown and Maintenance Deep-Dive.

Troubleshooting: Kranzle leaking oil from the bottom of the casing - Kranzle Pump Oil Leak.
Troubleshooting: Kranzle Inlet Leaking Water - Garden Hose Connection.
Troubleshooting: I just got my Kranzle and it's dripping / leaking oil!
Troubleshooting: Kranzle tripping with foam cannon even on a 20A circuit.
Why does my Kranzle pressure gauge show a high or low pressure-reading?

The full Custom Installed Kranzle Solution with a shelf, hose reel, wand/gun/holder, etc. is a different item. I want you to be able to buy the pump by itself if that's what you want. I've included some options here to allow you to create a system that's mobile.

Tier:
Ultimate Solution
- Kranzle K1322TS Pressure Washer
- Inlet Hose w/ Stainless Steel Garden Hose QDs
- 50’ High-Pressure Hose w/ Mosmatic T304 Stainless Steel ⅜” Female QD Couplers and M22 Female (14mm) to ⅜” QD Plug
- OG Spec Mosmatic Swiveling Sprayer w/ Mosmatic T304 Stainless Steel QDs
- OG Spec Mosmatic Wand w/ Mosmatic T304 Stainless Steel QDs
- Mosmatic Stainless Steel Nozzle Assembly w/ 4.0 Orifice - 40-degree and 25-degree
- MTM PF22.2 Foam Cannon w/ 1.25mm Orifice and Mosmatic T304 Stainless Steel ¼” Male QD Plug

Advanced Solution
- Kranzle K1322TS Pressure Washer
- Inlet Hose w/ Stainless Steel Garden Hose QDs
- 50’ High-Pressure Hose w/ MTM Stainless Steel 3/8" Female QD Couplers and M22 Female (14mm) to 3/8" QD Plug
- Original Mosmatic Swiveling Sprayer w/ MTM Stainless Steel QDs
- Original Mosmatic Wand w/ MTM Stainless Steel QDs
- MTM Stainless Steel ¼” Nozzle 4 Pack - 4.0 Orifice
- MTM PF22.2 Foam Cannon w/ 1.25mm Orifice and MTM Stainless Steel ¼” Male QD Plug

Basic Solution
- Kranzle K1322TS Pressure Washer
- Inlet Hose w/ Brass Garden Hose QDs
- 50’ High-Pressure Hose w/ MTM Stainless Steel 3/8" Female QD Couplers and M22 Female (14mm) to 3/8" QD Plug
- MTM SGS-28 Swiveling Sprayer w/ MTM Stainless Steel QDs
- Original Mosmatic Wand w/ MTM Stainless Steel QDs
- MTM Stainless Steel ¼” Nozzle 4 Pack - 4.0 Orifice
- MTM Original Foam Cannon w/ 1.25mm Orifice and MTM Stainless Steel ¼” Male QD Plug


Inlet Hose Length:
- 6.5’
- 12’
- 20’


Specifications

Kranzle K1322TS
- Tested Flow: 1.9 GPM
- Tested Pressure: 1010 PSI
- Tested Current: 13.5 A with 4.0 Orifice Nozzle, 16.2 A with 1.25mm Orifice Foam Cannon
- 3 Piston Wobble Plate Pump
- Self-Priming
- Auto-start/stop
- 35’ Power Cord with GFCI
- Electrical Requirements: 110 V, 15 A (Recommended 20 A circuit for use with foam cannons)
- Inlet: ¾” Female GHT
- Outlet: M22 Male (14mm)
- Dimensions: 18.75” W x 7” D x 12.5” H
- Weight: 43 LBS

Warranty Information
Kranzle offers a 1-year warranty for commercial use, and 2 years for home use. Info about their warranty can be found HERE. If you ever have a problem with your machine, reach out to us, not Kranzle. They will send you back to us since you bought it from OG. Before you send us an email though, try to work through the issues yourself in our FAQ and Support tab. Sometimes it’s a simple fix if you’re having trouble.


Sprayers:
Ultimate - OG Spec Mosmatic Swiveling Sprayer
- T304 Stainless Steel Quick Disconnects
- Mosmatic swivel integrated into the sprayer handle
- Low Trigger Force Trigger
- Custom blue faceplate with Obsessed Garage logo
- Max Tempurature: 300 °F (150 °C)
- Max Pressure: 5,000 PSI (350 BAR)
- Max Flow: 12 GPM (45 L/min)
- Warranty: 6 months, for manufacturing defects (does not include o-rings)

Advanced - Original Mosmatic Swiveling Sprayer w/ QDs
- MTM Stainless Steel Quick Disconnects
- Mosmatic swivel on the inlet of the sprayer
- Low Trigger Force Trigger
- Max Temp: 300 °F (150 °C)
- Max Pressure: 5000 PSI (350 BAR)
- Max Flow: 12 GPM (45 L/min)
- Mosmatic Sprayer Warranty: 6 Months, for manufacturing defects
- MTM fittings Warranty: 60 Days, for manufacturing defects. (This does not include o-rings)

Basic - MTM SGS-28 Swiveling Sprayer with Quick Disconnects
- MTM Stainless Steel Quick Disconnects
- MTM swivel on the inlet of the sprayer
- Easy Pull Trigger
- Max Temp: 320 °F (160 °C)
- Max Pressure: 4060 PSI (28 MPa)
- Max Flow: 12 GPM (45 L/min)
- Made in Italy
- Warranty: 60 days, for manufacturing defects. (This does not include o-rings)


Wands:
Ultimate - OG Spec Mosmatic 20° Bent Wand
- 20° Bend
- Made in Switzerland
- T304 Stainless Steel Quick Disconnects
- Max Temp: 300 °F (150 °C)
- Max Pressure: 5000 PSI (350 BAR)
- Max Flow: 12 GPM (45 L/min)
- Warranty: 6 months, for manufacturing defects (does not include o-rings)

Advanced/Basic - Original Mosmatic Swiveling Sprayer w/ QDs
- MTM Stainless Steel Quick Disconnects
- Mosmatic swivel on the inlet of the sprayer
- Low Trigger Force Trigger
- Max Temp: 300 °F (150 °C)
- Max Pressure: 5000 PSI (350 BAR)
- Max Flow: 12 GPM (45 L/min)
- Mosmatic Sprayer Warranty: 6 Months, for manufacturing defects
- MTM fittings Warranty: 60 Days, for manufacturing defects. (This does not include o-rings)


Nozzles:
Ultimate - OG Spec Mosmatic Nozzle Assembly
- T304 Stainless Steel
- ¼” QD Plug Connection
- Rubber Nozzle Guard
- Warranty: 6 months, for manufacturing defects

Advanced/Basic - Stainless Steel 1/4" Nozzle 4 Pack
- Stainless Steel
- ¼” QD Plug Connection
- Warranty: 60 days, for manufacturing defects


Foam Cannons:
Ultimate/Advanced - MTM PF22.2 Foam Cannon
- Nickel Plated Brass - Single Cast Foam Cannon Body
- Two-way adjustable spray pattern
- 32oz Wide Bottom Bottle
- ¼” QD Plug Connection
- Min Pressure: 1,100 PSI - Max Pressure: 5,000 PSI
- Min Flow: 1.4 GPM - Max Flow: 5.3 GPM
- Max Temperature: 140°F
- Made in Italy
- Warranty: 60 days, for manufacturing defects

Basic - MTM Original Foam Cannon
- Brass Foam Cannon Body
- Adjustable spray pattern
- 32oz Bottle
- ¼” QD Plug Connection
- Min Pressure: 1,100 PSI - Max Pressure: 5,000 PSI
- Min Flow: 1.4 GPM - Max Flow: 5.3 GPM
- Max Temperature: 140°F
- Made in Italy
- Warranty: 60 days, for manufacturing defects


High-Pressure Hose:
Ultimate/Advanced/Basic - High-Pressure 3/8" Pressure Washer Hose
- ⅜” Inside Diameter
- ⅝” Outside Diameter
- Ends terminated in ⅜” Male NPT
- Single Wire Construction
- Smooth Jacket in Non-marking Blue
- Rubber Bend Restrictors
- Max Pressure: 4000 PSI
- Max Temperature: 275 °F
- Warranty: 60 days, for manufacturing defects


Inlet Hose:
Garden Hose
- Brand: Continental
- ⅝” Inside Diameter
- Ends terminated in ¾” GHT


Fittings:
Ultimate - Mosmatic T304 SS 3/8" Female QD Coupler
- Brand: Mosmatic
- Material: T304 Stainless Steel
- Inlet: ⅜” Male NPT
- Outlet: ⅜” QD Coupler
- Warranty: 6 months, for manufacturing defects (does not include o-rings).

Advanced/Basic - Stainless Steel 3/8" Female QD Coupler
- Brand: MTM
- Material: Stainless Steel
- Inlet: ⅜” Male NPT
- Outlet: ⅜” QD Coupler
- Warranty: 60 days, for manufacturing defects (does not include o-rings).

Ultimate - Mosmatic T304 SS M22 Female (14mm) to 3/8" QD Plug
- Brand: Mosmatic
- Material: T304 Stainless Steel
- Inlet: M22 Female (14mm)
- Outlet: ⅜” QD Plug
- Warranty: 6 months, for manufacturing defects (does not include o-rings).

Advanced/Basic - Stainless Steel M22 Female (14mm) to 3/8" QD Plug
- Brand: MTM
- Material: Stainless Steel
- Inlet: M22 Female (14mm)
- Outlet: ⅜” QD Plug
- Warranty: 60 days, for manufacturing defects.

Ultimate/Advanced - Stainless Steel Garden Hose 3/4” Female QD Coupler
- Brand: MTM
- Material: Stainless Steel
- Inlet: ¾” Female GHT
- Outlet: ¾” QD Coupler
- Warranty: 60 days, for manufacturing defects.

Basic - Brass Garden Hose 3/4” Female QD Coupler
- Brand: MTM
- Material: Brass
- Inlet: ¾” Female GHT
- Outlet: ¾” QD Coupler
- Warranty: 60 days, for manufacturing defects.

Ultimate/Advanced - Stainless Steel Garden Hose 3/4” Male QD Plug
- Brand: MTM
- Material: Stainless Steel
- Inlet: ¾” Male GHT
- Outlet: ¾” QD Plug
- Warranty: 60 days, for manufacturing defects.

Basic - Brass Garden Hose 3/4” Male QD Plug
- Brand: MTM
- Material: Brass
- Inlet: ¾” Male GHT
- Outlet: ¾” QD Plug
- Warranty: 60 days, for manufacturing defects.

Some of the items in this package will be shipped from OGHQ in Lady Lake, FL. Some components will be dropshipped from supplier warehouses.


ETA Information:

(Kranzle)- If you are ordering this unit you are looking at Q3 2022 for an ETA. (Mosmatic couplers) There is a larger batch arriving in early June. (Inlet Hose)- 6.5’ - Late May
